S200-8XTMY-AC

·8*10g SFP+ ports, 12MB cache.

·Support static routing, OSPF/RIP,satisfy the L3 transmission requirement.

·Strong networking security policies,abundant safe features to protect networking.

·Support CLI,WEB,Cloud multiple management methods.

· White shell, low power design, environmental protection and energy saving.


S200-8XTMY-AC features 8*10G SFP+ optical ports. Each RJ45 port supports auto-port switching and line-rate forwarding capabilities. Utilizing store-and-forward technology with QoS integration, it ensures efficient bandwidth allocation across all ports for stable data transmission. The system provides multiple management options including CLI, web interface, and cloud-based administration, delivering intuitive operation and simplified maintenance.

Overview
Parameter
Application
Files










Provider Mode Ports
Fixed Port

8*1000/2500/5000/10000  Base-T

Management PortSupport console
Power InterfaceAC Interface
LED IndicatorsPWR ,  SYS,  Link/ACT LED
Cable Type&Transmission Distance

Twisted Pair Cable

0-100m(CAT5e,CAT6)

Network Topology
Ring TopologySupport
Star TopologySupport
Bus TopologySupport
Tree TopologySupport
Hybrid TopologySupport
Electrical Specifications
Input VoltageAC 100-240V 50/60Hz

Main Board Power

<60W
Layer 2 Switching
Switching Capacity160Gbps
Packet Forwarding Rate119.04Mpps
MAC Address Table16K
Buffer12Mbit
Forwarding Delay<10us
Polarity Reversal Support
VLAN Support Quantity4000
GARP VLANSupport
 Protocol VLANSupport
Voice VLANSupport
Surveillance VLANSupport
MAC VLANSupport
Ethernet Channel/802 .3adSupport
LACPSupport
Interface SpeedSupport
 Flow ControlSupport
Jumbo FrameSupport
DHCP ClientSupport
SNTP ClientSupport
Port StatisticsSupport
Protected PortsSupport
EEESupport
Ethernet Ring Protection SwitchingSupport
LLDPSupport
LLDP 802.1 TLVSupport
MSTP / RSTP /STPSupport
STP BPDU FilterSupport
STP BPDU GuardSupport
STP Port FastSupport
IGMP SnoopingSupport
MLD SnoopingSupport
MVRSupport
DHCP Interface Prioritizes IP bindingSupport
Device Scanning Support
Layer 3 Route
IPV4 management addressSupport
IPV6 management addressSupport
Static Routes IPv4Support
Static Routes IPv6Support
ARPSupport
Loopback InterfaceSupport
DHCP ServerSupport

VRRP

Support

Dynamic Routing

OSPF、RIP
Convergence
ACLSupport MAC standard/extended ACL
Support IPv4 standard/extended ACL
Support IPv6 standard/extended ACL
QOSSupport QoS retagging
Support port trust
Support port Rate Limiting
Support export queue speed limit
Support SP and WRR scheduling algorithms
Support COS mapping, DSCP mapping, IP priority mapping
Management
User ManagementSupport
SyslogSupport
Upgrade FirmwareSupport
Configuration File Download/UploadSupport
SNMPSNMP V1/V2/V3
WEB Support
ConsoleSupport
CLISupport
Telnet/SSHSupport
RMONSupport
Security
Manage Channel ConfigurationSupport
AAASupport
802.1XSupport
MAC-Based AuthorizationSupport
WEB-Based AuthorizationSupport
Anti-DoSSupport
DAISupport
DHCP SnoopingSupport
IP Source GuardSupport
Port SecuritySupport
Protected PortsSupport
Storm ControlSupport
Equipment diagnosis
Console LogSupport
RAM LogSupport
Flash LogSupport
Port MirroringSupport 1:1 or 1:M
PingSupport
TracerouteSupport
Electrical Interface TestingSupport
Optical Module InformationSupport
UDLDSupport

EMC&Ingress Protection

Operating Temperature

-10℃~+55℃

Storage Temperature

-40℃~+75℃

Relative Humidity

10% to 90% RH

Heat Dissipation Method

Fan cooling

MTBF

100,000 hours

Mechanical Dimensions

Product Size270*181*44mm
Weight
1.32KG
Installation MethodDesktop installation
EMC&Ingress Protection
Surge Protection of PowerCommon model 6KV Differential model 2KV
Surge Protection of Ethernet portCommon model 4KV Differential model 2KV
ESDTouch 8K ,Air 15K
Free Fall0.5m
Accessories
Accessories

Device, power cord, user manual
